I-beams are widely used in the construction field. It can be used to build roofs, build bridges, support building structures, etc. For example, when building high-rise buildings, a large number of I-beams are used to support the structure of the building, ensuring the stability and safety of the entire building.
| MODEL | H | B | S | T | KG/M |
| IPE 80 | 80 | 46 | 3.8 | 5.2 | 6 |
| IPE A 80 | 78 | 46 | 3.2 | 4.2 | 5 |
| IPE AA 80 | 78 | 46 | 3.2 | 4.2 | 4.95 |
| IPE AAA 80 | 78 | 46 | 3 | 4 | 4.69 |
| IPE AAAA 80 | 76 | 46 | 2.9 | 3.1 | 3.99 |
| IPE 100 | 100 | 55 | 4.1 | 5.7 | 8.1 |
| IPE A 100 | 98 | 55 | 3.6 | 4.7 | 6.9 |
| IPE AA 100 | 98 | 55 | 3.6 | 4.5 | 6.72 |
| IPE AAA 100 | 97 | 55 | 3.4 | 4.3 | 6.41 |
| IPE AAAA 100 | 96 | 55 | 2.9 | 3.6 | 5.46 |
| IPE 120 | 120 | 64 | 4.4 | 6.3 | 10.4 |
| IPE A 120 | 118 | 64 | 3.8 | 5.1 | 8.7 |
| IPE AA 120 | 117 | 64 | 3.8 | 4.8 | 8.36 |
| IPE AAA 120 | 117 | 64 | 3.5 | 4.6 | 7.9 |
| IPE AAAA 120 | 115 | 64 | 3.0 | 3.9 | 6.73 |
| IPE 140 | 140 | 73 | 4.7 | 6.9 | 12.9 |
| IPE A 140 | 137 | 73 | 3.8 | 5.6 | 10.5 |
| IPE AA 140 | 137 | 73 | 3.8 | 5.2 | 10.05 |
| IPE AAA 140 | 136 | 73 | 3.5 | 5.0 | 9.52 |
| IPE AAAA 140 | 134 | 73 | 3.0 | 4.1 | 8.3 |
| IPE 160 | 160 | 82 | 5.0 | 7.4 | 15.8 |
| IPE A 160 | 157 | 82 | 4.0 | 5.9 | 12.7 |
| IPE AA 160 | 156 | 82 | 4.0 | 5.6 | 12.31 |
| IPE AAA 160 | 156 | 82 | 3.7 | 5.4 | 11.76 |
| IPE AAAA 160 | 154 | 82 | 3.6 | 4.3 | 10.24 |
| IPE 180 | 180 | 91 | 5.3 | 8.0 | 18.8 |
| IPE A 180 | 177 | 91 | 4.3 | 6.5 | 15.4 |
| IPE AA 180 | 176 | 91 | 4.3 | 6.2 | 14.94 |
| IPE AAA 180 | 176 | 91 | 3.9 | 6.0 | 14.13 |
| IPE AAAA 180 | 174 | 91 | 3.9 | 4.9 | 12.57 |
| IPE 200 | 200 | 100 | 5.6 | 8.5 | 22.4 |
| IPE A 200 | 197 | 100 | 4.5 | 7.0 | 18.4 |
| IPE AA 200 | 196 | 100 | 4.5 | 6.7 | 17.9 |
| IPE AAA 200 | 196 | 100 | 4.1 | 6.5 | 17.12 |
| IPE AAAA 200 | 193 | 100 | 4.1 | 5.2 | 15.02 |
| IPE 220 | 220 | 110 | 5.9 | 9.2 | 26.2 |
| IPE A 220 | 217 | 110 | 5.0 | 7.7 | 22.2 |
| IPE 240 | 240 | 120 | 6.2 | 9.8 | 30.7 |
| IPE A 240 | 237 | 120 | 5.2 | 8.3 | 26.2 |
| IPE 270 | 270 | 135 | 6.6 | 10.2 | 36.1 |
| IPE 300 | 300 | 150 | 7.1 | 10.7 | 42.2 |
| IPE 330 | 330 | 160 | 7.5 | 11.5 | 49.1 |
| IPE 360 | 360 | 170 | 8.0 | 12.7 | 57.1 |
| IPE 400 | 400 | 180 | 8.6 | 13.5 | 66.3 |
| IPE 450 | 450 | 190 | 9.4 | 14.6 | 77.6 |
| IPE 500 | 500 | 200 | 10.2 | 16.0 | 90.7 |
| IPE 550 | 550 | 210 | 11.1 | 17.2 | 106 |
| IPE 600 | 600 | 220 | 12.0 | 19.0 | 122 |
I Beam
I Beam
I Beam
I Beam
I Beam
I Beam
