U channel is known for its strongness, firmness, and high strength, making it an ideal material for the construction and machinery manufacturing sectors. With high strength, U channel is able to resist strong vibrations from various works. By producingU channel in a wide range of sizes and qualities, it is flexible to meet the special technical requirements of various projects and projects.U channel are not only resistant to harsh environmental conditions, such as changeable weather and high temperatures, but also to the effects of chemicals. This makes it a common material in many industries, from machine building to construction.
| EN STANDARD U CHANNEL | |||
| Specification | Web thickness | Flange thickness | Theoretical Weight |
| Depth*flange width | (mm) | (mm) | (kg/m) |
| UPN 80 80*45 | 6 | 8 | 8.64 |
| UPN 100 100*50 | 6 | 8.5 | 10.6 |
| UPN 120 120*55 | 7 | 9 | 13.4 |
| UPN 140 140*60 | 7 | 10 | 16 |
| UPN 160 160*65 | 7.5 | 10.5 | 18.8 |
| UPN 180 180*70 | 8 | 11 | 22 |
| UPN 200 200*75 | 8.5 | 11.5 | 25.3 |
| GB STANDARD U CHANNEL | ||||
| Specification | Web mm | Flange mm | Web thickness | Theoretical Weight (kg/m) |
| 5# | 50 | 37 | 4.5 | 5.438 |
| 6.3# | 63 | 40 | 4.8 | 6.634 |
| 8# | 80 | 43 | 5 | 8.045 |
| 10# | 100 | 48 | 5.3 | 10.007 |
| 12# | 120 | 53 | 5.5 | 12.059 |
| 14A# | 140 | 58 | 6 | 14.535 |
| 14B# | 140 | 60 | 8 | 16.733 |
| 16A# | 160 | 63 | 6.5 | 17.24 |
| 16B# | 160 | 65 | 8.5 | 19.752 |
| 18A# | 180 | 68 | 7 | 20.174 |
| 18B# | 180 | 70 | 9 | 23 |
| 20A# | 200 | 73 | 7 | 22.637 |
| 20B# | 200 | 75 | 9 | 25.777 |
| 22A# | 220 | 77 | 7 | 24.999 |
| 22B# | 220 | 79 | 9 | 28.453 |
| 25A# | 250 | 78 | 7 | 27.41 |
| 25B# | 250 | 80 | 9 | 31.335 |
| 28A# | 280 | 82 | 7.5 | 31.427 |
| 28B# | 280 | 84 | 9.5 | 35.823 |
| 30A# | 300 | 85 | 7.5 | 34.463 |
| 30B# | 300 | 87 | 9.5 | 39.173 |
| 32A# | 320 | 88 | 8 | 38.083 |
| 36A | 360 | 96 | 9 | 47.814 |
| 36B | 360 | 98 | 11 | 53.466 |
| 36C | 360 | 100 | 13 | 59.118 |
| 40A | 400 | 100 | 10.5 | 58.928 |
| 40B | 400 | 102 | 12.5 | 65.208 |
| 40C | 400 | 104 | 14.5 | 71.488 |
| JIS STANDARD U CHANNEL | |||
| Dimension (mm) | T1 | T2 | KG/M |
| 50*25 | 3.00~5.00 | 6 | 2.37~3.46 |
| 75*40 | 3.8 | 7 | 5.3 |
| 75*40 | 4 | 7 | 5.6 |
| 75*40 | 4.5 | 7 | 5.85 |
| 75*40 | 5 | 7 | 6.92 |
| 100*50 | 3.8 | 6 | 7.3 |
| 100*50 | 4.2 | 6 | 8.03 |
| 100*50 | 4.5 | 7.5 | 8.97 |
| 100*50 | 5 | 7.5 | 9.36 |
| 125*65 | 5.2 | 6.8 | 11.66 |
| 125*65 | 5.3 | 6.8 | 12.17 |
| 125*65 | 5.5 | 8 | 12.91 |
| 125*65 | 6 | 8 | 13.4 |
| 150*75 | 5.5 | 7.3 | 14.66 |
| 150*75 | 5.7 | 10 | 16.71 |
| 150*75 | 6 | 10 | 17.9 |
| 150*75 | 6.5 | 10 | 18.6 |
| 200*80 | 7.5 | 11 | 24.6 |
| 250*90 | 9 | 13 | 34.6 |
| 300*90 | 9 | 13 | 38.1 |
